Neousys Nuvo-9501: Review

Neousys Nuvo-9501: Review

Reviewing the Neousys Nuvo-9501

Nuvo-9501 is a cost-effective compact fanless embedded computer based on the Intel 13th/12th-Gen platform.

Built on the advanced Intel 7 process, Intel 13th Gen processors offer up to 24 cores/ 32 threads to deliver up to 2x the performance when compared to previous Intel 10th or 11th Gen platforms. Nuvo-9501 is a cost-effective, compact and yet powerful fanless embedded computer that offers the ultimate computing for various industrial applications.

Nuvo-9501 Features & Highlights

As a cost-effective and compact embedded computer, Nuvo-9501 delivers excellent computing performance and offers essential necessary I/O connectivityons to meet customers’ needs and cost. It is suitable for a variety of industrial applications.

  • Intel® 13th/12th-Gen Core™ 35W/ 65W LGA1700 CPU
  • Compact 212 x 165 x 80 mm footprint
  • Rugged, -25°C to 60°C fanless operation (Nuvo-9505D only)
  • Up to 32GB DDR4 3200 SODIMM
  • 2x 2.5GbE and 4x USB3.2 Gen 1 with screw-lock
  • Supports 1x M.2 2280 Gen4 x4 NVMe and 1x 3.5″/2.5″ SATA HDD/SSD storage
  • 4-CH isolated DI and 4-CH isolated DO (Nuvo-9505D only)
  • VGA + DP dual display outputs

Robust & Reliable Specs

Nuvo-9501 offers essential I/O functions for general industrial needs including dual 2.5GbE ports, dual display ports and four USB3.2 ports. In addition, it features a Gen4 x4 M.2 NVMe slot for the latest NVMe SSDs with read/ write speeds up to 7000 MB/s.

Also, it supports a 2.5” or 3.5” HDD storage for high capacity storage needs such as data collection or surveillance applications. It also offers two mPCIe and one M.2 E key slots for installing WiFi or 5G/ 4G wireless communication modules.

System Specs

PROCESSOR
Supporting Intel® 13th-Gen Core™ CPU* (LGA1700 socket, 65W/ 35W TDP)
– Intel® Core™ i9-13900E/ i9-13900TE
– Intel® Core™ i7-13700E/ i7-13700TE
– Intel® Core™ i5-13500E/ i5-13400E/ i5-13500TE
– Intel® Core™ i3-13100E/ i3-13100TE
– Intel® Celeron® G6900E/ G6900TE

Supporting Intel® 12th-Gen Core™ CPU
(LGA1700 socket, 35W/ 65W TDP)
– Intel® Core™ i9-12900E/ i9-12900TE
– Intel® Core™ i7-12700E/ i7-12700TE
– Intel® Core™ i5-12500E/ i5-12500TE
– Intel® Core™ i3-12100E/ i3-12100TE
– Intel® Pentium® G7400E/ G7400TE
– Intel® Celeron® G6900E/ G6900TE

CHIPSET
Intel® H610E platform controller hub

MEMORY
Up to 32GB non-ECC DDR4 3200 SDRAM (one SODIMM slot)

GRAPHICS
Integrated Intel® UHD Graphics 770 (32EU) / 730 (24EU)

I/O

ETHERNET
2x 2.5GBASE-T Ethernet ports by Intel® I226-V GbE controllers (Nuvo-9501)
2x 2.5GBASE-T Ethernet ports by Intel® I226-IT GbE controllers (Nuvo-9505D)

VIDEO
1x VGA output, supporting 1920 x 1200 resolution
1x DisplayPort, supporting 4096 x 2304 resolution

USB
4x USB 3.2 Gen1 (5 Gbps) ports
2x USB 2.0 ports

SERIAL
1x software-programmable RS-232/422/485 ports (COM1)
3x 3-wire RS-232 ports (COM2/3/4) or 1x RS-422/485 port (COM2)

AUDIO
1x 3.5 mm jack for mic-in and speaker-out

Storage

SATA
1x internal SATA port for 3.5″ HDD or 2.5″ HDD/ SSD

M.2
1x M.2 2280 M key socket (PCIe Gen4 x4) for NVMe SSD

Expansion

MINI PCI EXPRESS
2x full-size mini PCI Express sockets with internal SIM sockets

M.2
1x M.2 2230 E key socket for WiFi5, WiFi6 or Google edge TPU module

Full System Specs

With a compact footprint on Intel’s 13th/12th-Gen Core 35W/65W LGA1700 CPU, the Nuvo-9501 is packed with features.

Download the Full Spec Sheet for Nuvo-9501 Here

Recommendation

Nuvo-9501 is a cost-effective compact fanless embedded computer built on the advanced Intel 7 process.

As a cost-effective and compact embedded computer, Nuvo-9501 delivers excellent computing performance and offers essential necessary I/O connectivityons to meet customers’ needs and cost. It is suitable for a variety of industrial applications.
